Medmount Medical 45 Degree Three-Speed Zoom Optical System Mobile Ent Operation Microscope for Fine Surgical Examination

Still deciding? Get samples of $ !
Request Sample

Product Description

Basic Info

Model NO.
WT-OPEM-01
Magnification of Binocular
6X
Interpupillary Distance
50mm-80mm
Diopter
+/- 5D
Magnification Changer
F=200 & F=300mm
Total Magnification
3X-12X
Linear Field
15.8mm-60.8mm
Beamsplitter
50:50 or Not
Video Camera Adapter
C-Mount or Not
Fine Focusing Range
10mm
Filter
Built-in Green and Yellow
Balancing Arm
2-Part Arm/ Adjustable Arm
Illumination System
LED Coaxial Illumination
Production Capacity
500 Pieces/ Day

Product Description

1. Surgical microscope is a multi-functional, multi-purpose medical optical instrument. It is widely used in otolaryngology, dentistry, ophthalmology, gynecology and surgery and other departments of microsurgery.

2. The operating microscope uses led lamp coaxial lighting, with different working distance and magnification. It is easy to operate and use.

3. This product is suitable for suturing small blood vessels and nerves, as well as other fine surgeries or examinations.

4. It provides surgeons or other operating room staff with magnification and high-quality images of small structures to help surgeons achieve better treatment results.

5. Surgical microscopes can be connected to camera adapters and demonstrators, providing a clearer field of view and helping doctors perform more accurate and safe surgical operations.

Detailed Specifications

Item WT-101 WT-102 WT-103 WT-104 WT-120 WT-130
Binocular observationStraight45º TiltedStraight45º TiltedStraight45º Tilted
Magnification of binocular6X
Interpupillary distance50mm-80mm
Diopter±5D
Magnification changer3-step: 0.6X, 1X, 1.6X
Focal lengthF=200 & F=300mm
Total magnification3X, 5X, 8X, 4.7X, 7.5X, 12X
BeamsplitterNo50:50 Beamsplitter
IlluminationCoaxial 10W LED, >30000lx
📷

Detailed Images

Why Choose Us

Quality AssuranceStrict ISO13485 & ISO9001 compliance. Most products are CE/FDA certified.
2 Years Warranty24-month quality assurance and life-long maintenance service.
CustomizationFull support for product modifications and custom molds for global clients.
Quick Response24-hour service with responses typically within 2 hours.
Fast DeliveryAddressing urgent needs with pre-shipment quality inspections.
Customer FirstDare to take responsibility and align with customer business risks.

Company Overview

Process and Quality Control
?

Frequently Asked Questions

What medical departments can use this operation microscope?
It is widely used in otolaryngology (ENT), dentistry, ophthalmology, gynecology, and various microsurgery departments.
What is the magnification range of the WT-OPEM-01?
The total magnification ranges from 3X to 12X, with a 3-step magnification changer (0.6X, 1X, 1.6X).
What type of lighting system does the microscope use?
It features a high-brightness LED coaxial illumination system (10W) with adjustable brightness exceeding 30,000lx.
Is it possible to record video or take photos during surgery?
Yes, the system supports optional accessories like beamsplitters (50:50) and C-mount adapters for video cameras and demonstrators.
Does the microscope come with built-in filters?
Yes, it includes built-in green and yellow filters to assist in different surgical environments.
What is the warranty period for this equipment?
We provide a 2-year quality warranty and life-long maintenance service for all our operation microscopes.
